W60HAP
Wi-Fi 6 Dual-Band In-Wall Panel Access Point
802.11ax dual-radio wall-plate AP with 3000Mbps, Gigabit WAN/LAN, 86x86mm in-wall form factor, 128 clients and 802.3af PoE.
- 3000Mbps
- MAX SPEED
- Wi-Fi 6
- POE
- 86x86
- IN-WALL
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax |
|---|---|
| Max Speed | 2976 Mbps (2.4G 574 + 5G 2402) |
| MIMO | 2.4G: 2 streams, 2x2 MU-MIMO / 5G: 2 streams, 2x2 MU-MIMO |
| Client Capacity | 128 concurrent clients |
| Deployment | In-wall installation (standard 86mm junction box) |
| Ports | 1x 10/100/1000M WAN port, 1x 10/100/1000M LAN port, 1x Reset/Mesh button, 1x tri-color SYS LED |
| Form Factor | In-wall panel, 86 x 86 x 44 mm |
| Use Cases | General education, higher education, government, finance, business, hotels, offices |
The W60HAP is a dual-radio 802.11ax-compliant wall plate wireless access point from Foredge, designed for education, government, finance and business indoor scenarios. It delivers up to 3000 Mbps aggregate (574 + 2402 Mbps) with 2x2 + 2x2 MIMO, Gigabit WAN and LAN ports, 128 concurrent clients and 8 BSSIDs. Installed in a standard 86x86 mm junction box, powered by 802.3af PoE at 15W. Managed via Foredge AC, APOLLO Cloud or local web. The cost-effective choice for hotel and office in-wall deployments.
MAX SPEED
3000Mbps
POE
Wi-Fi 6
IN-WALL
86x86
