HAEC-OSFP-800G
800G OSFP Active Electrical Cable
800Gbps active electrical cable with OSFP, 112G PAM4 per lane, up to 6m reach, 30AWG and ≤10W per end.
- 800Gbps (112G PAM4/lane)
- SPEED
- AEC, 5m / 6m
- TYPE
- OSFP
- CONNECTOR
| Speed | 800Gbps (112G PAM4/lane) |
|---|---|
| Type | AEC, 5m / 6m |
| Connector | OSFP |
The Foredge 800G AEC supports 800Gbps with 112G PAM4 per lane, widely used in data centers and high-density network equipment. It offers 100% compatibility with all major brands of servers, switches and routers. The OSFP active electrical cable features pull-to-release sliding latch, 30AWG wire, 3.3V DC operation, ≤10W per end and up to 6m transmission distance. Operating temperature 0 to 70 °C, compliant with OSFP MSA, PAM4 and RoHS. Available in 5m and 6m lengths.
SPEED
800Gbps (112G PAM4/lane)
TYPE
AEC, 5m / 6m
CONNECTOR
OSFP
